Particle Defect Inspection System

The Fastmicro Particle Defect Inspection System has been developed to measure surface particle contamination levels directly on a product’s surfaces in any industry down to 200 nm Lower Detection Limit (LDL) at very fast throughput speeds.

The primary applications are in Semiconductor (pellicles, reticles, wafers) and the display market. The scanning area is expandable to very large surfaces, like LCD substrates due to its modular and scalable design.

The scanner module is also available as a white label OEM solution for system integrators.

​The Fastmicro Particle Defect Inspection System Applications

PDS can be used for particle measurements on:

• Up to 400 wafers/hour​

• No moving or rotating wafer stage​

• Simultaneous front & back side inspection​

• Compatible with silicon, compound, glass wafers, pellicles, reticles    ​

• High depth of focus​

• No degradation of sensitive photoresist layers​

• Replace multiple legacy systems with one .    ​

• Pre-scan for follow up analysis ​

• Current sensitivity 200 nm​

• Supports manual and automated processing for up to 12-inch wafers​

• Multi-product recipes and interfaces available
